Senseair K96紅外多合一氣體模塊
- 產品品牌：瑞典SenseAir
- 產品型號：K96
- 所屬分類：紅外氣體傳感器
A small, versatile, and high precision 3-channel NDIR sensor
A breakthrough in the NDIR sensing! With the K96 sensors, Senseair introduces a very novel approach to measure simultaneously up to 3 different species with one mid-IR source. The sensor has excellent performance such as high accuracy and long lifetime.
Senseair K96 is designed for high volume production with full traceability by sensor serial number on all manufacturing processes and key components. Every sensor is individually calibrated and is provided with UART digital interface. The sensor is maintenance-free.
Senseair K96 is a module that is designed for simple integration into products. It offers new cost-effective alternatives for a wide variety of applications from GHG (CO2, CH4) monitoring at urban or industrial scales to indoor air quality studies in specific environments (N2O, CO)
Senseair K96規格：
Measured gas：Carbon Dioxide (CO2), Methane (CH4), Carbon Monoxide (CO), Nitrous Oxide (N2O), Hydrocarbons (HC), Water Vapour (H2O)
Operating Principle：Non-dispersive infrared (NDIR)
Measurement range：CO2: 0～3000 ppm；CH4: 0～3000 ppm；CO: 0～80 ppm；N2O: 0～1000 ppm
Accuracy：TBD
Maintenance：Periodic 1 point calibration
Life Expectancy：15 years in normal commercial environments
Power supply：6～8.5 VDC
Operation temperature：0～50°C
Communication & outputs：UART (Modbus, FastStream)
Dimensions：33.9×43×26mm
Energy consumption：300mA peak, 120mA average
Pin headers：Optional
Self-diagnostics：A full system test is executed automatically every time the power is turned ON
Senseair K96主要優勢：
Up to 3 species measured simultaneously
High precision
Maintenance free
Long term stability
Long lifetime
Individually calibrated with temperature and pressure compensation
